Technical Specifications:
- Display 4.3 inches TFT-LCD (480*272)
- Operation Panel Silicon Rubber
- Language Chinese & English & Others
- Digital Input 9
- Analogue Input 10
- Digital Output 12
- Monitor Interface RS485
- Programmable Interface USB/RS485
- IP Protection Class IP55
- DC Supply DC(8¡«35)V
- Case Dimensions(mm) 266*182*45
- Panel Cutout(mm) 214*160
- Operating Temp. (-25¡«+70)℃
Performance and characteristics 480x272 pixel, 4.3 inches coloured TFT-LCD with backlight, multilingual interface (including English, Chinese or other languages) which can be chosen at the site, making commissioning convenient for factory personnel.
Improved LCD wear-resistance and scratch resistance due to hard screen acrylic.
Silicon panel and pushbuttons for better operation in high/low temperature environment.
RS485 communication port enabling remote control, remote measuring, remote communication via ModBus protocol.
Equipped with CANBUS port and can communicate with J1939 genset. Not only can you monitoring frequently-used data (such as water temperature, oil pressure, engine speed, fuel consumption and so on) of ECU machine, but also control start, stop, raising speed and speed droop via CANBUS port.
GOV Function; outlet pressure and inlet pressure can be adjusted via GOV function. GOV port: Relay output; Analog output (for speed control unit); CANBUS port (for engine control unit).
The controller detects not only engine speed but also gearbox speed.
Water pressure curve and flow curve are user-defined.
10 analog sensors; sensors can switch between resistor type and current type using jumper.
More kinds of curves of temperature, oil pressure, fuel level can be used directly and users can define the sensor curves by themselves.
