Smartgen Diesel Engine Automatic High Voltage Battery Charger BAC06H for Generator


Price:
$99
 More payment options

Description

Smartgen diesel generator set (genset) battery charger

BAC06H battery charger adopts the latest switch power components, which is designed for charging lead-acid starting battery according to its property. The charger is suitable for the lead-acid battery float charge. BAC06H is a kind of high voltage charger and its input voltage can be reached at 480V. The maximum charge current for 12V charger is 6A; the maximum charge current for 24V charger is 3A.

Characteristics:

1.Switch power supply structure, wide input AC voltage range, small size, lightweight, high-efficiency rate;

2. Users can select an automatic two-stage charging process or automatic three-stage charging process as needed. Both the two charging process is carried out according to storage battery charging characteristics to prevent overcharging and significantly prolong battery lifetime;

3. Built-in PFC circuit can calibrate the power factor above 0.99;

4. Built-in current protective circuit for overcurrent protection, short-circuit protection and reverse connection protection. The output will be recovery automatically after the failure is removed.

5. Battery voltage detection ports can detect the battery voltage in real-time.

6. Battery low voltage output port; It will output low level immediately after the battery voltage has fallen below the set value for preset delay.

7. Temperature sensor port allows for monitoring the battery temperature in real-time and temperature compensation function which can prevent the battery temperature is too high effectively.

8. Mains failure port; It will output low level immediately when the AC input is interrupted.

9.Standard RS485 communication port.

10.BACM1206 charger is suitable for 12V battery;rated current:6A;

11.LED display: Full charged indication (Green light) and charging indication (Red light).
